NON STOP STATION CI FLEXOGRAPHIC PRINTING PRESS

NON STOP STATION CI FLEXOGRAPHIC PRINTING PRESS

One of the key advantages of this printing press is its non-stop production capability. The NON STOP STATION CI flexographic printing press has an automatic splicing system that enables it to print continuously without any downtime. This means that businesses can produce larger volumes of printed materials in a shorter amount of time, enhancing productivity and profitability.


  • MODEL: CHCI-E Series
  • Machine Speed: 300m/min
  • Number of printing decks: 4/6/8
  • Drive Method: Gear Drive
  • Heat source: Gas, Steam, Hot oil, Electrical heating
  • Electrical supply: Voltage 380V. 50 HZ.3PH or to be specified
  • Main Processed Materials: Films; Paper; Non-Woven; Aluminium foil, paper cup
  • Product Detail

    Product Tags

    Technical Specifications

    Model CHCI6-600E CHCI6-800E CHCI6-1000E CHCI6-1200E
    Max. Web value 650mm 850mm 1050mm 1250mm
    Max. Printing value 600mm 800mm 1000mm 1200mm
    Max. Machine Speed                  300m/min
    Printing Speed                  250m/min
    Max. Unwind/Rewind Dia.                  φ800mm
    Drive Type                  Gear drive
    Plate thickness                  Photopolymer plate 1.7mm or 1.14mm (or to be specified)
    Ink                  Water base ink or solvent ink
    Printing length (repeat)                  350mm-900mm
    Range Of Substrates                  LDPE; LLDPE; HDPE; BOPP, CPP, PET; Nylon,PAPER,NONWOVEN
    Electrical supply                  Voltage 380V. 50 HZ.3PH or to be specified

    Video introduction

    Machine Features

    ●One of the standout features of the Non Stop Station CI flexographic printing press is its continuous printing capability. With this machine, you can achieve non-stop printing, which helps you to increase productivity and reduce downtime.

    ●In addition, the Non Stop Station CI flexographic printing press is equipped with advanced automation features that make it easier and faster to set up and run jobs. automatic ink viscosity controls, print registration, and drying are just a few of the features that streamline the printing process.

    ●Another advantage of the Non Stop Station CI FLEXOGRAPHIC PRINTING PRESS is its high print quality. This technology uses advanced software and hardware that ensure precise and accurate printing, producing high-quality prints even at high speeds. This quality is critical for companies that require consistent and reliable prints for their products, as it helps them maintain brand consistency and customer satisfaction.



    Details Display

    1
    2
    3
    4

    Printing Samples

    01
    02
    03
    04
